| Standard & Protocol |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3z for 1000Base-X
IEEE802.3ae for 10GBase-X
IEEE 802.3x for Flow Control
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1Q for VLAN
IEEE 802.1p for CoS
IEEE 802.1AB for LLDP
ITU-T G.8032 for ERPS |
| Management |
SNMP v1/v2c/v3 Centralized Management of Equipment, RMON, Port Mirroring, QoS, LLDP, DHCP Server, DHCP Relay, File Management, Port Statistics, Log Information, Syslog Server, Static ARP |
| Security |
Classification of User Permissions, NAT, Alarm Configuration, Storm Suppression, SSHD Configuration, Telnet Configuration, Loop Detection, Link Flapping Protection, HCP Snooping |
| Switch Function |
802.1Q VLAN, Port Trunking, Bandwidth Management, Flow Control, Port Isolation |
| Unicast / Multicast |
Static Multicast, IGMP, IGMP-Snooping, PIM-SM, PIM-DM |
| Redundancy Technology |
Ring, STP/RSTP/MSTP, ERPS |
| Troubleshooting |
Ping, Traceroute, Port Loopback, SFP Digital Diagnosis |
| Routing Technique |
VRRP, RIP, OSPF, Multicast routing |
| Time Management |
NTP |
| Interface |
Gigabit copper port: 10/100/1000Base-T(X) self-adaptive RJ45, automatic flow control, support full/half duplex mode, MDI/MDI-X self-adaption
Gigabit SFP Slot : 100/1000 Base-X self-adaption SFP slot
10Gigabit SFP+: 1000/10G Base-X self-adaptive SFP+ slot
Console port: CLI command line management port(RS-232), RJ45
Alarm port: 6-pin 5.08mm pitch terminal blocks (2 pins for relay), support 1 relay alarm output
|
| Indicator |
Running Indicator, Alarm Indicator, Power Supply Indicator, Interface Indicator |
| Switch Property |
Transmission mode: store and forward
MAC address: 16K
Packet buffer size: 12Mbit
Backplane bandwidth: 128G
Switch time delay: <10μs |
| Power Supply |
12~48VDC, 6-pin 5.08mm pitch terminal blocks.
The power supply occupies 4 pins and supports dual power supply redundancy and anti-reverse connection. |
| Power Consumption |
No-load: 15.4W@24VDC
Full-load: 30W@24VDC |
| Working Environment |
Operating temperature: -40~65℃
Storage temperature: -40~85℃
Relative humidity: 5%～95%(no condensation) |
| Physical Characteristic |
Housing: IP30 protection, metal
Installation: DIN-Rail mounting
Dimension (W x H x D): 137.4mm×150mm×135mm
Weight: 2kg |
| Industrial Standard |
IEC 61000-4-2 (ESD, electrostatic discharge), Level 3
IEC 61000-4-4 (EFT, electrical fast transient pulses), Level 3
IEC 61000-4-5 (Surge), Level 3
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6 |
| Authentication |
CE, FCC, RoHS |
